◆English and Chinese screen display ,operation is simple .
◆PLC computer
system , function is more stable , adjustment any parameters not need stop
machine.
◆It can stock ten dispose , simple to change variety.
◆Sever
motor drawing film , position accurately.
◆Temperature independent control
system ,precision get to±1℃.
◆Horizontal , vertical temperature control
,suitable for various of mix film , PE film packing material.
◆Packing type
diversification , pillow sealing, standing type ,punching etc.
◆Bagmaking ,
sealing, packing, print date in one operation.
◆Work circumstance quiet, low
noise.
Technical characteristics:
Suitable packing powder : milk powder , bean powder ,etc.
|
Model |
BVP420F |
|
Bag length |
80-300mm(L) |
|
Bag width |
50-200mm(W) |
|
Max width of roll film |
420mm |
|
Packing speed |
5-60bags/min |
|
Measuring range |
150-1200ml |
|
Air consumption |
0.65MPa |
|
Gas consumption |
0.3m3 /min |
|
Power voltage |
220V |
|
Power |
2.2KW |
|
Dimension |
(L)1320mm×(W)950mm×(H)1360mm |
|
Machine weight |
540Kg |
|
Model |
DB-130 |
|
convey high |
800mm |
|
Transmission power |
40W |
|
convey measure |
200mm/min |
|
Dimensions |
1300×430×890mm |
|
Bag length |
螺杆旋转充填式 |
|
Packing Weight |
100-1000g |
|
Packing speed |
10-30bags/min |
|
Power Supply |
220V50-60HZ |
|
Packing Accuracy |
≤100g偏差(≤0.5-1g)100-1000g偏差(≤1%) |
|
Weighing scale |
100-1000ml |
|
Total Weight |
800KG |
